XtraFire™ Lintels

Naylor XtraFire™ concrete lintels are single cast lintels which have been independently tested for fire resistance by Warrington Fire and for loading by Lucideon.

More Information

XtraFire™ lintels are fire rated up to R240 minutes for load-bearing and are available in five sections in widths of 100mm, 140mm and 215mm.

XtraFire™ lintels have an ex steel mould finish similar to our current fairfaced product made from specialist wet cast concrete. Having pencil round edges but with a possibility of small air holes on the lintel surface.

Typical Application and Uses:

Naylor XtraFire™ lintels are suitable for use in the construction of a wide range of applications including:

  • Residential apartment blocks
  • Schools
  • Hospitals
  • Care homes
  • Shopping centres
  • Industrial and commercial
  • Leisure and sports stadia
  • Airports

Additional benefits of XtraFire™ lintels:

  • Independently fire tested by Exova Warrington Fire testing facility
  • Solid concrete 1 part unit -  no need for additional coatings
  • Cuttable on site
  • Smooth ex-steel mould finish
  • Durable product for stocking and storage
  • Can be used in aggressive environments
  • Can be exposed to cyclic wetting/drying
  • Cement replacement technology is used which requires less than 20% of the energy and produces less than 10% of the CO2 emissions compared to Portland cement production.

Product Certification

  • BS EN 1992-1-2: 2004 – Classification of fires
  • BS EN 845: Part 2: 2013 + A1: 2016 – Specification for ancillary components
  • BS EN 206: 2013 + A2: 2021 – Concrete specification performance production and conformity
  • BS 8500 -1: 2015 – Complimentary BS to BS EN 206
  • Prestressed wire complies with BS 5896: 2012 – High tensile steel wire and strand for the prestressing of concrete
